Description
Installation instructions:
Step 1:
Turn off water supply to toilet
Step 2:
Flush toilet and continue to hold down handle until toilet tank drains completely
Step 3:
Disconnect the water supply hose from toilet tank
Step 4:
Place the rubber washers inside the top and bottom ends of T-valve and apply the Teflon tape to the T-valve thread
Step 5:
Connect the female end of the T-valve to the toilet tank.
Do not over tighten
Step 6:
Connect the water supply hose to male end (bottom) of T-valve.
Do not over tighten
Step 7:
Connect the sprayer hose to the remaining port on the T-valve and connect sprayer head to hose.
Make sure rubber washers are placed in both ends of hose.
Do not over tighten
Step 8:
Mount the sprayer holder on side of toilet tank using the included hanger, or on the wall using the included screws
Step 9:
Restore water pressure with T-valve in down (off) position and allow toilet tank to fill completely.
Check for leaks
Step 10:
Adjust sprayer pressure using T-valve lever and make sure lever on T-valve is in off position when not in use
